Additional information
Weight | 132.0000 lbs |
---|---|
Dimensions | 22.5000 × 23.5625 × 32.3125 in |
Basic Information Appliance type 020 Overall appliance dimensions (HxWxD) 817 x 598 x 550 mm Color Galvanized Quick Wash Option No Comfort Status indicator End of program audible, Water inlet Time Remaining PowerBeam Yes sideLight No emotionLight No emotionlight pro No Connection Watts 1,440 W Power cord length 120.0 cm Fuse protection 12 A Length inlet hose 165 cm Length outlet hose 190 cm Plug type Nema5-15P Size and weight Overall appliance dimensions (HxWxD) 817 x 598 x 550 mm Depth with open door 90 degree 1,155 mm Maximum height for installation (in.) 877 mm Minimum width for installation 610 mm Maximum width for installation 618 mm Depth for installation 550 mm Height of removable worktop 0 mm Net weight 53.6 kg Weight furniture front (min – max) 2.5 – 8.5 kg Size and weight Previous Next Previous Next Operation TFT display indicating remaining or end time, refill for salt and rinsing agent, inflow of water. Touch key operation. Flexible cycle time reduction, even during an active cycle. Personalization function for storing individual combinations of programs. Temporary noise reduction (only available with active Home Connect functionality). Information key with use indicators. Sanitized indicator in the control panel. Time delay up to 24 hours. Visual and acoustic end of program indicator. Remaining time projection. Technical Features Perfectly illuminated interior. Glass protection with zeolite. Aqua sensor. Load sensor. Automatic detergent function. Yes Flow-Through Water Heater(TM) Triple filter system. Soft lock. Aqua stop. Home network integration for digital services (Home Connect) wireless via WiFi. The use of the Home Connect functionality depends on the Home Connect services, which are not available in every country. For further information please check: home-connect.com. Programs 8 programs:Auto 150-160 (degree)F. Auto 127-140 (degree)F. Auto 113-122 (degree)F. Eco 113-136 (degree)F. Wash and Dry 122(degree)F. Quick Wash 113 (degree)F (30 min). Glass Care 122 (degree)F. Personalization function (default setting: Pre-rinse). 6 options:Remote Start Intensive. Power. Sanitize. Extra Dry with zeolite. Machine Care. Features Flexible rack system with smooth running rails on all levels and soft-closing system of the upper and lower rack. 3rd rack for cutlery. Upper basket:Over extension. Optional extra cleaning area by activating additional spray nozzles. Rackmatic with 3 levels, adjustable in height up to 2″ (5 cm). 6 folding spines. 4 folding racks for optimal protection of glass. Lower basket:8 folding spines. 2 folding racks for optimal protection of glass. Dividable glass support. Cutlery basket. Holder for long-stemmed glasses. 13 place setting capacity. Maximum glass loading capacity 23 wine glasses. Consumption data Energy Star certified Total annual energy consumption 269 kWh. Noise level 42 dB (re 1 pW). Planning notes Height-adjustable feet. Appliance toe-kick recess 3 15/16″ (see drawing). To display the remaining time projection, a minimum toe-kick protrusion is required (1 9/16″ + thickness of the cabinet front). The maximum toe-kick height must be reduced by 1 1/16″ to provide an optimal display of the remaining time projection. Rear feet adjustable at front. Door weight up to 18 lb. Door panel dimension dependent on toe-kick height of kitchen cabinetry. Installation and usage also with custom cabinet handle possible. The push-to-open function remains active. Rating Total rating: 1440 W. Connection to hot or cold water possible. Connecting cable 47 1/4″ with three-prong plug (NEMA 5-15P). Show All Technical Information
-
Brand | GAGGENAU |
---|---|
Category | Dishwasher:Kitchen Appliances |
Model Number | DF480700 |
UPC/GTIN | 825225965053 |
Shipping Class | 85 |
Capacity | 13.0000 |
Color | |
Width | 23 9/16 |
Height | 32 5/16 |
Weight | 132.00 |
Depth | 22 1/2 |
Weight | 132.0000 lbs |
---|---|
Dimensions | 22.5000 × 23.5625 × 32.3125 in |
